The MSD300 is a sending card developed by NovaStar. It supports 1x DVI input, 1x audio input, and 2x Ethernet outputs. A single MSD300 supports input resolutions up to 1920×1200@60Hz.
The MSD300 communicates with PC via type-B USB port. Multiple MSD300 units can be cascaded via UART port.
As a highly cost-effective sending card, the MSD300 can be mainly used in the rental and fixed installation applications, such as concerts, live events, security monitoring centers, Olympic Games and various sports centers.
MSD300 Sending Card
1.1 DVI video input;
2.1 audio input;
3.2 Ethernet port outputs;
4.USB control interface which is able to be cascaded for uniform control;
5.Single sending card supports resolution of 1280×1024, 1024×1200, 1600×848, 1920×712 or 2048×668;
6.1 light sensor interface.
MSD600 Sending Card
It has the following charecterstics:
1.HDMI/DVI input;
2.HDMI/extermal audio input;
3.12bit/10bit/8bit HDvideo source;
4.Resolution supported:2048*1152,1920*1200,2560*960;
5.Resolution supported:1440*900;(12bit/10bit)
6.1 light sensor interface;
7.Cascading supported;
8.18bit gray scale processing and presentation;
9.Video format:RGB,YCrCb4:2:2,YCrCb4:4:4;
Specifications
Further Information:
MSD300-Sending-Card-Specifications-V2.3.0
MSD600 Sending Card Specifications-V2.2.1(1)
